MI 3205 TeraOhm XA 5kV Main menu
22
4.2 Custom tests
This menu contains a list of custom prepared tests. The commonly used tests are added to
the list by default or user. Up to 30 custom tests can be pre-programmed.
Figure 4.2: Custom Test Menu
Keys:
 
Select one of the following menu items:
SELECT
Confirms selection.
ESC
Returns to the Main menu.
4.2.1 Creating custom test
The user has an option to save any custom made parameter settings.
Simply enter the desired measurement, edit the test parameters end press MEM key.
The insert text screen will appear if no result is left for save.
Figure 4.3: Insert text screen
Keys in Insert text screen:
 
Selects a letter.
SELECT
Selects the next letter.
MEM
Confirm name and return to the selected measurement.
ESC
Deletes last letter.
Returns to selected measurement without changes.
