Metrix CX 1651

Calibrateur multifonctions CX 1651
Manuel de l'utilisateur 175
DCI uncertainty
range % value + % range max. voltage V
0 µA - 200 µA
0.05 + 0.0 + 20 nA 3
200 µA - 2 mA
0.02 + 0.005
3
2 mA - 20 mA 0.01 + 0.003
3
20 mA - 200 mA 0.01 + 0.003
3
200 mA - 2 A 0.015 + 0.005
3
2 A - 20 A 0.02 + 0.010
1.5
ACI uncertainty
range % value + % range max voltage Vef % value + % range max voltage Vef
20 Hz - 1 kHz 1 kHz – 5 kHz
1 µA - 200 µA
0.15 + 0.0 + 20 nA 3 0.30 + 0.10 + 20 nA 3
200 µA - 2 mA
0.07 + 0.01 3 0.20 + 0.05 3
2 mA - 20 mA 0.05 + 0.005 3 0.20 + 0.05 3
20 mA – 200 mA 0.05 + 0.005 3 0.20 + 0.05 3
200 mA – 2 A 0.05 + 0.005 3 - - - -
2 A - 20 A 0.10 + 0.03 1.5 - - - -
range % value + % range max voltage Vef
5 kHz – 10 kHz
1 µA - 200 µA
- - - -
200 µA - 2 mA
0.50 + 0.07 2
2 mA - 20 mA 0.50 + 0.07 2
20 mA - 200 mA 0.50 + 0.07 2
200 mA - 2 A - - - -
2 A - 20 A - - - -
When option 130-50, 140-50 Current Coil is used, add uncertainty 0.3% of the set current to the value specified in above table. Output
current is multiplied by factor 50.
Auxiliary parameters
range 200 uA 2 mA 20 mA 200 mA 2 A 10 A
maximal inductive load
400 uH 400 uH 400 uH 400 uH 200 uH 100 uH
THD
*1
0,2% 0,2% 0,2% 0,2% 0,2% 0,3%
*1
parameter includes non-linear distortion and non-harmonic noise
Function Shape
current range: 100 uA to 2 A
wave form: square, positive, negative, symmetrical, ramp A, ramp B, triangle
truncated sin with THD 13,45 %
peak value uncertainty: 0.3 % + 500 nA
displayed values: peak, effective
Minimum frequency for squarewave signals is 0.1 Hz, for all others 20 Hz.
Resistance
summary range: 0 Ω to 50 MΩ
Resistance uncertainty
resistance range uncertainty of value [%] current range
0 Ω - 100 Ω 0.03 + 10 mΩ
1 mA - 40 mA
100 Ω - 400 Ω
0.015
400 µA - 20 mA
400 Ω - 2 kΩ
0.015
100 µA - 4 mA
2kΩ - 10 kΩ
0.015
20 µA - 1 mA
10 kΩ - 40 kΩ
0.015
4 µA - 200 µA
40 kΩ - 200 kΩ
0.015
1 µA - 40 µA
200kΩ -1 MΩ
0.05
0.2 µA - 10 µA
1 MΩ - 4 MΩ
0.1
40 nA – 2 µA
4 MΩ - 20MΩ
0.2 10 nA – 500 nA
20 MΩ - 50MΩ
0.5 4 nA – 150 nA
