Calibrateur multifonctions CX 1651
176 Manuel de l'utilisateur
Maximal allowed voltage on output terminals is 8 V
pp
. Uncertainty is valid for four-terminal connection with use of Option 70 or Option
140-41 Cable adapters. For two-wire connection from the terminals Hi-Lo na the front panel add to the specified uncertainty next +10
mOhm.
Capacitance
summary range: 0.9 nF to 50 µF
Capacitance uncertainty
range uncertainty of value [%] max. frequency
900 pF - 2.5 nF 0.5 + 15 pF 1000 Hz
2.5 nF - 10 nF 0.5 + 5 pF 1000 Hz
10 nF - 50 nF 0.5 1000 Hz
50 nF – 250 nF 0.5 1000 Hz
250 nF - 1 µF
0.5 500 Hz
1 µF – 2.5 µF
1 300 Hz
2.5 µF - 5 µF
1 300 Hz
5 µF – 10 µF
1.5 300 Hz
10 µF - 50 µF
2.0 300 Hz
Maximal allowed voltage on output terminals is 8 V
pp
.
AC and DC power/energy
summary voltage range: 0.2 V to 240 V
current capability of voltage output: depends on the voltage range
summary current range: 2 mA to 10 A
maximal voltage on current output: depends on the current range
power range: 0.0004 to 2.4 kVA
time period range: 1.1 s to 1999 s
frequency range: DC, 40 Hz to 400 Hz
DCV uncertainty
See table of DCV uncertainty.
DCI uncertainty
range % value + % range
max. voltage [V]
2 mA - 20 mA 0.05 + 0.010
3
20 mA - 200 mA 0.05 + 0.005
3
200 mA - 2 A 0.05 + 0.005
3
2 A – 10 A 0.05 + 0.010
1.5
DC POWER uncertainty
Uncertainty of DC power can be calculated from the following formula:
d P = √ ( dU
2
+ dI
2
+ 0.01
2
) [%]
where dP is uncertainty of output power [%]
dU is uncertainty of set voltage [%]
dI is uncertainty of set current [%]
DC ENERGY uncertainty
Depends on voltage, current, time values. The best uncertainty is 0.016 %.
ACV uncertainty
See table of ACV uncertainty.
