Metrix CX 1651 User Manual

Calibrateur multifonctions CX 1651
Manuel de l'utilisateur 179
Temperature sensors simulation
temperature scale: ITS 90, PTS 68
types of sensors: RTD, TC
A. RTD (resistance) sensors
types: Pt 1.385, Pt 1.392, Ni
range of R0 setting: 20 Ω to 2 kΩ
temperature range: -200 to +850
o
C
temperature uncertainty: 0.04
o
C to 0.5
o
C (see table bellow)
Ranges and uncertainties of RTD sensor simulation
type
range –200 – 250
o
C range 250 – 850
o
C
Pt100 0.1
o
C 0.3
o
C
Pt200 0.1
o
C 0.2
o
C
Pt1000 0.2
o
C 0.4
o
C
Ni100 0.07
o
C
*1
- -
*1
Valid in range –60 to +180
o
C.
Uncertainties in the table are maximal uncertainties of RTD sensor simulation. Actual uncertainty for each set value of
simulated temperature is determined by uncertainty of relevant resistance. Actual temperature uncertainty is displayed on the
calibrator display. Actual uncertainties are always lower than those in above table.
B. TC sensors:
types: K, N, R, S, B, J, T, E
temperature range: -250 to +1820
o
C according to the type
temperature uncertainty: 0.4 to 4.3
o
C (see table bellow)
Ranges and uncertainties of TC sensor simulation (with function AUTOCAL ON)
R range [
o
C] -50 - 0 0 - 400 400 – 1000 1000 – 1767
uncertainty [
o
C] 3.2 2.1 1.4 1.7
S range [
o
C] -50 - 0 0 - 250 250 – 1400 1400 – 1767
uncertainty [
o
C] 2.7 2.1 1.7 2.0
B range [
o
C] 400 – 800 800 - 1000 1000 – 1500 1500 – 1820
uncertainty [
o
C] 2.8 1.8 1.6 1.8
J range [
o
C] -210 - -100 -100 - 150 150 – 700 700 – 1200
uncertainty [
o
C] 0.9 0.5 0.6 0.7
T range [
o
C] -200 - -100 -100 - 0 0 – 100 100 – 400
uncertainty [
o
C] 0.9 0.5 0.4 0.4
E range [
o
C] -250 - -100 -100 - 280 280 – 600 600 – 1000
uncertainty [
o
C] 1.6 0.4 0.5 0.5
K range [
o
C] -200 - -100 -100 - 480 480 – 1000 1000 – 1372
uncertainty [
o
C] 1.0 0.6 0.7 0.8
N range [
o
C] -200 - -100 -100 - 0 0 – 580 580 – 1300
uncertainty [
o
C] 1.2 0.7 0.6 0.8
Uncertainties in the table are maximal uncertainties of TC sensor simulation. Actual uncertainty for each set value of
simulated temperature is determined by uncertainty of relevant resistance. Actual temperature uncertainty is displayed on the
calibrator display. Actual uncertainties are always lower than those in above table.
