Metrix CX 1651 User Manual

Calibrateur multifonctions CX 1651
180 Manuel de l'utilisateur
Multimeter
Measuring: DC voltage
DC current
resistance, temperature
strain gauge sensors
Ranges and uncertainties
function total range uncertainty (%) resolution / range
DC voltage - DCV
*1
0 to +/-12 V
0.01 % + 300 µV 100µV / 10V
DC voltage - mVDC
*1
0 to +/-2 V
0.02 % + 7 µV
20mV / 100nV, 200mV / 1uV, 2V / 10uV
DC current
*1
0 to +/-25 mA 0.015 % + 300 nA 100 nA/20mA
Frequency 1 Hz to 15 kHz 0.005
10 µHz – 0.1 Hz
Resistance
*2
0 to 2.5 k Ω 0.02% + 10 m Ω 20Ω / 1mΩ, 200Ω / 1mΩ, 2kΩ / 10mΩ
Temperature - Pt sensor -200 to +850
o
C
*3
0.1
o
C 0.1
o
C
Temperature – TC sensor -250 to +1820
o
C see Table 0.01
o
C
Strain gauge sensors
*4
depends on sensor
0.05 % + 10 µV + uncertainty of sensor
*1
Uncertainties are valid after performing ZERO correction in set mode
*2
Measuring current 1 mA
*3
For Pt 1000 sensor maximum temperature is 350
o
C
*4
Supply voltage: 2 to 10 V DC, non-symmetrical
Max. current: 40 mA
Input resistance: min. 100 MΩ
Sensitivity: setable in range 0.5 mV to 100 mV /V
Displayed unit : user´s defined
Ranges and uncertainties of temperature measuring with TC sensor
R range [
o
C] -50 - 0 0 – 400 400 – 1000 1000 – 1770
uncertainty [
o
C] 2.5 1.5 1.0 1.2
S range [
o
C] -50 - 0 0 – 250 250 – 1400 1400 – 1770
uncertainty [
o
C] 2.0 1.6 1.1 1.3
B range [
o
C] 400 - 800 800 – 1000 1000 – 1500 1500 – 1820
uncertainty [
o
C] 2.0 1.3 1.2 1.1
J range [
o
C] -210 - -100 -100 – 150 150 – 700 700 – 1200
uncertainty [
o
C] 0.7 0.4 0.4 0.6
T range [
o
C] -200 - -100 -100 - 0 0 – 100 100 – 400
uncertainty [
o
C] 0.8 0.5 0.4 0.4
E range [
o
C] -250 - -100 -100 - 280 280 – 600 600 – 1000
uncertainty [
o
C] 1.1 0.4 0.4 0.5
K range [
o
C] -200 - -100 -100 - 480 480 – 1000 1000 – 1372
uncertainty [
o
C] 0.8 0.4 0.6 0.8
N range [
o
C] -200 - -100 -100 – 0 0 – 580 580 – 1300
uncertainty [
o
C] 0.9 0.5 0.5 0.8
Sorting function
Output GO/NG: 1 x make, 1 x break contacts, 50Vpp / 100mA
Triggering : external, internal, manual
