2.1 Instrument connectors
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
8
￭￭￭￭￭￭￭￭
912/913/914 Meter
2.1.2 913 pH Meter | 913 pH/DO Meter
Figure 2 913 pH Meter - Connectors
1
pH/mV electrode
Connection socket for analog pH/mV elec-
trodes.
2
Temperature sensor / reference
3
pH/mV electrode | O
2
Lumitrode
Connection socket for connecting iTrodes
with 854 iConnect or the O
2
Lumitrode.
4
Type B mini USB connector
Connection socket for energy supply, data
transmission and printing.
2.1.3 914 pH/DO/Conductometer
Figure 3
pH/DO/Conductometer (digital) - Connectors
1
Conductivity measuring cell
Connection socket for conductivity measur-
ing cells.
2
pH/mV electrode | O
2
Lumitrode
Connection socket for connecting iTrodes
with 854 iConnect or the O
2
Lumitrode.
3
Type B mini USB connector
Connection socket for energy supply, data
transmission and printing.
