3.3 Connecting sensors
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
16
￭￭￭￭￭￭￭￭
912/913/914 Meter
3.3 Connecting sensors
NOTICE
Connecting the sensor
Sensors can be connected while the instrument is running.
NOTICE
Parameter setting
Please note that if you change the sensor, the sensor either has to be
selected in the Menu ▶ Parameters X ▶ Measuring parame-
ters ▶ Sensor name menu dialog, or a new sensor has to be entered
in the sensor list.
NOTICE
iConnect for iTrodes
Sensors from the iTrodes line are only supported by the 854 iConnect
series 07 or higher.
The series is indicated by the number 17 in the following serial number
example:
1854001017216
3.4 Disconnecting sensors
CAUTION
Cable damage
The connection cable can get damaged if it is handled incorrectly.
￭ Only remove the connection cable by pulling on the plug.
￭ Do not remove the connection cable by pulling on the cable.
