5 Installation
915 KF Ti-Touch
￭￭￭￭￭￭￭￭
21
The 6.2151.000 controller cable is required for connecting a Sample Pro-
cessor.
Connect the Sample Processor as follows:
1
Connect the Sample Processor to the power grid.
2
Connect the Sample Processor to the Ti-Touch with the controller
cable.
The Sample Processor will be recognized automatically and entered
in the device manager of the Ti-Touch.
NOTE
The plug on the controller cable is protected against accidental
disconnection by means of a pull-out protection feature. If you
wish to pull out the plug, you first need to pull back the outer plug
sleeve marked with arrows.
3
Configure the Sample Processor in the device manager.
5.6 Setting up the titration vessel
The tutorial for the 915 KF Ti-Touch includes a detailed description of how
to set up the Karl Fischer titration cell and what needs to be taken into
account while doing so.
5.7 Connecting sensors
5.7.1 General
The measuring interface includes one measuring input (Pol.) for a polariz-
able electrode and one measuring input (Temp.) for a temperature sensor
(Pt1000 or NTC).
5.7.2 Connecting a polarizable electrode
Connect the polarizable electrode as follows:
1
Plug the electrode plug into the Pol. socket of the Ti-Touch.
