5 Installation
915 KF Ti-Touch
￭￭￭￭￭￭￭￭
13
5.3 Mounting the KF titration cell
The KF titration cell can be mounted with the aid of the upper part of KF
titration cell.
NOTE
To prevent damage to the KF titration cell, the permissible height above
the stirrer can be fixed with the aid of the clamping ring at the upper
part of the KF titration cell.
Proceed as follows:
1
Push the clamping ring (6.2013.010) down as far as possible onto
the mounted support rod (6.2016.050). Make sure while doing so
that the indent is facing upwards.
2
Fix the 6.1414.030 vessel lid of the KF titration cell (with correctly
inserted sealing ring from the 6.1244.040 sealing set) to the support
rod.
3
Keep the locking lever pressed down and push the vessel lid down.
4
Fasten the 6.1415.220 (or 6.1415.250) KF titration cell with a
6.1903.020 (or 6.1903.030) stirring bar inside on the vessel lid. Fold
back the holding bracket upwards while doing so. The markings on
the vessel lid and on the plastic ring must be aligned above one
another. Afterwards, press the holding bracket downwards in order
to fix the KF titration cell. The levers of the holding bracket must
enclose the pins of the plastic ring on the KF titration cell in order to
ensure a secure hold.
5
Adjust the height of the KF titration cell by pressing the locking lever.
It should almost touch the surface of the stirrer.
6
Readjust the clamping ring to the KF titration cell position and screw
tight to fix the position of the KF titration cell. Make sure that the
nose of the electrode holder is placed in the opening of the clamping
ring.
If the height of the KF titration cell has been adjusted correctly, the
entire cell can be raised and swiveled as required by pressing the
locking lever.
