CHAPTER 1: INTRODUCTION
4
MVP motor Vee plate kit
PN 40.215.184.01
20 lb
(9.1 kg)
Fine tunes the horizontal aim of arrays; compatible with
MTG-LEO-M, MTG-LYON, MTG-1100, MG-LEOPARD/900,
and MG-MINA/LINA/750-LFC grids.
—
3/4-inch or
7/8-in
PBF-LINA
pull-back frame kit
PN 40.271.080.01
4 lb
(1.8 kg)
Attaches to bottom of LINA and 750-LFC arrays (to the bottom
cabinet) and provides pull-back for extreme array downtilt
0.25 in x 0.90 in
(black button with 6 in
lanyard),
PN 134.036,
qty 2 included
1/2-in
MCF-MINA/LINA
caster frame kit
(PN 40.207.102.01)
28 lb
(12.7 kg)
Safely transports up to five LINA cabinets, making it easy to
assemble and disassemble arrays in blocks of five cabinets
0.25 in x 0.90 in
(black button with 6 in
lanyard),
PN 134.036,
qty 4 included
—
MCF-750 (rigging)
caster frame kit
PN 40.271.070.02
34 lb
(15.4 kg)
Safely transports up to three 750-LFC cabinets. This caster
frame is for cabinets with equipped with MRK-750 rigging.
0.25 in x 0.90 in
(black button with 6 in
lanyard),
PN 134.036,
qty 4 included
—
MCF-750 (no rigging)
caster frame kit
PN 40.271.070.03
28.7 lb
(13.0 kg)
Safely transports up to three 750-LFC cabinets. This caster
frame is for cabinets without rigging.
no pins —
35MM Pole Stand
Adapter
assembly kit
PN 40.010.971.01
0.36 lb
(0.16 kg)
This large base stand adapter can be used to mount the
MYA-MINA/LINA Yoke or MUB-MINA/LINA on a pole to allow
easy tilting of a MINA or LINA.
——
MPK-POLE-35MM-M20
Adjustable Pole Mount
kit
(PN 40.010.973.01)
8 lb
(3.62 kg)
Adjustable length 927–1524 mm (36.5–60 in), 35 mm (1.375 in)
pole with assisted lift. Lower shaft fits 35mm cups or use the
removable M20 threaded lug for added stability. Upper shaft
includes a PAS-M20 Adapter Sleeve to fit loudspeakers with
35mm and M20 internal pole mounts onto a 35 mm speaker
stand. (Can also buy the PAS-M20 Adapter Sleeve separately).
Additional 35 mm to 38 mm (1.5 in) adapter included.
——
Table 1: LINA and 750-LFC Rigging Options
