CHAPTER 4: LOUDSPEAKER GUIDEALINKS
16
NOTE: For Ultra-weatherized versions of the LINA (see “ULTRA Weather Protection Version” on page 83), the
11° position is not available.
NOTE: The splay angles listed on the GuideALink label are for relative angles between the center axes of the
linked units. For example, setting the GuideALink to “5” yields a 5-degree downtilt of the lower unit relative to
the upper unit. How the loudspeakers relate to the floor, stage, and seating angles in the venue depends on the ori-
entation of the MG-MINA/LINA/750-LFC grid, the angles of the loudspeakers in the array above them, whether they
are flown or ground-stacked, and other factors. MAPP can be used to calculate optimum splay angles for loudspeak-
ers and to predict coverage patterns for arrays.
NOTE: Optimal acoustical performance for LINA arrays is achieved by using the appropriate number of units
and appropriate splay angles to meet the coverage requirements of the venue. You can use MAPP to verify
designs and rigging configurations.
