MGE UPS Systems Pulsar Evolution 800 - UPS Front Panel Controls

34007117EN/AB - Page 9
1
2
%
%
1.3 Control panel
Bargraph indicating percent load at output.
Group 1 programmable outlets supplied with power.
Iluminated ON/OFF button for the outlets.
Group 2 programmable outlets supplied with power.
Operation on battery power.
10
11
12
15
14
18
17
13
16
1. Presentation
UPS fault.
Battery fault.
Overload.
Booster or fader mode.
Bargraph indicating the battery charge level.
0 to 25%.
26 to 50%.
51 to 75%.
76 to 100%.
