8.26 Out 1 Function (Door closed/Stairway Fan Out)
• Door Closed = sends a signal when the door is Closed.
• Stairway Fan Out = sends a signal when the door is Open.
• Use the "UP" and "DOWN" buttons to select the setting.
8.27 Pull Before Open (Yes/No)
• This setting will Pull/Push the door closed for a fraction of a second before the activation to open the electric
strike.
• Give a clear Opening once the Strike/Lock has been released.
• Caution: Set the electric Lock Delay to a minimum of 0.2 seconds.
8.28 Reverse on Obstruction (Yes/No)
• This setting will Enable or Disable the Re-activation feature.
• If Enabled, the Re-activation is generated if the door encounters an obstruction for at least 2 seconds during
the Closing cycle, between the Back-check and the Latch areas.
• Use the "UP" and "DOWN" buttons to Enable or Disable this feature.
8.29 Power Shut (Yes/No)
• WARNING: You should always install a Presence Safety sensor when Enabling this feature.
• This setting is to Enable or Disable the Power Shut feature.
• When Power Shut is "ON", the motor will assist the spring driving the door during the Closing cycle from a 90
Open position to the fully Closed position.
This feature is used when the application is exposed to constant high winds conditions that prevents
the door from Closing properly and smoothly.
• Use the "UP" and "DOWN" buttons to Enable or Disable this feature.
8.30 Power Shut Force (01-05)
• This setting will allow you to increase or decrease the amount of Closing Force needed to fully Close the door
from the 90 position to fully closed position.
This feature is used to counteract High Wind conditions.
• IMPORTANT: When using the Power Shut Force feature, you must connect a Presence Safety sensor into the
input "PC Cancel" on the control board terminal that Cancels out this feature when a pedestrian presence is
detected. C = Power Close.
• Use the "UP" and "DOWN" buttons to select the desired Closing Force. Use the lowest Force setting needed to
ensure positive Latching in these conditions.
• Check this setting is correctly adjusted.
8.31 Software Version MSWO1 v. X.XX
• This menu will display the Software version in the Control unit where X equals a numeric value.
• The month and year of the Control manufacturing date will be displayed.
