Micom SW800 - Section 2.0 - Technical Specification

SW800 Installation Manual
5
Section 2.0 - Technical Specification
1.0
Model
SW800
2.0
Application
Low Energy Swing Door Operator
3.0
Power Supply
100V - 240V AC, 50/60 Hz
4.0
Consumption
100W Max
5.0
Motor
1/4 Hp, Low revolution 24 DC, 3A Max
6.0
Rated Operation
Continuous opening and closing cycles
7.0
Reduction Gear
Enclosed Reduction Gear system
8.0
Control System
Microprocessor Digital Control
9.0
Operating Environment
Ambient temperature: -18 ~ +50
(no condensation or icing)
Ambient humidity 30% to 85% RH
(no hazardous materials must be present in the
atmosphere)
10.0
Operation During Power Failure
Low manual resistance when opened by hand. Door
closing by spring.
11.0
Operator Net Weight
17 kg, approx. 38 lbs.
12.0
Operator Dimensions
5½" (h) (140 mm) x 4½" (D) (115 mm)
13.0
Door Weight (max)
700 lbs. (318 kg) per leaf
14.0
Door Width Limits
29" up to 60" (consult factory for special sizes)
15.0
Operator Width
29" to 102"
16.0
Installation Types
Push, Pull, Overhead Concealed, Center spindle
17.0
Adjustable Opening Angle
80 to 180
18.0
Auxiliary Power
500mA @ 24 vdc for accessories AND
1,000mA @ 12 vdc for accessories
19.0
Closing Force
Adjustable pressure by spring tension and optional
motor close
20.0
Product Standards
UL 325 Listed by ETL #5012330
ANSI 156.19 Compliant
UL10C Fire Door Rated Operator - 2 hours
