MICRO-EPSILON IF2030/ENETIP User Manual

Page 16
Commissioning
IF2030/ENETIP
5. Commissioning
5.1 Configuring the Sensors
The sensor used must be correctly configured to work with the IF2030. Micro-Epsilon recommends that the sensor’s base configura-
tion be set by using its web interface. The configuration can later also be adjusted via fieldbus.
Please refer to the operating instructions of the corresponding sensor for detailed information on configuring the sensor.
5.2 Baud Rate and Sensor Interface
IF2030/ENETIP must be set for the interface used and the sensor’s baud rate.
Sensor/
Controller
Baud rate [Baud] Bus address RS485 RS422
Sensor/
Controller
Baud rate [Baud] Bus address RS485 RS422
ACC5703 230400 126 • ILD1750 921600 •
ACS7000 230400 • ILD1900 921600 •
DT6120 230400 126 • ILD2300
921600
1
•
IFC24x1 115200 • INC5701 230400 126 •
IFC242x 115200 • MSC7602 256000 •
ILD1320 921600 • ODC2520 115200 •
ILD1420 921600 •
Fig. 11 Baud rate (factory setting) of the sensors or controllers to be connected
The baud rate and sensor interface are transferred with Class 0xA0 (Object), see Chap. 5.4.
1) The ILD2300 is set for 691.2 kBaud ex factory. Increase the baud rate to 921.6 kBaud in the sensor.
