Annex | Sensor Values, Data Format, Conversion
IF2030/ENETIP
A 3.10 INC5701
Baud rate 230400 b/s RS485 half duplex max. sampling rate 250 Hz, ex factory INC5701D, Little Endian
Bus address 126
Byte Meaning Data format
Data[0] Status byte (contains error flags, normaly 0x00) 8 bit
Data[1] Long term values counter [bit 0:7] Uint 32 bit
Data[2] Long term values counter [bit 8:15]
Data[3] Long term values counter [bit 16:23]
Data[4] Long term values counter [bit 24:31]
Data[5] Number of measured values in this package 8 bit
Data[6] Padding byte 8 bit
Data[7] Padding byte 8 bit
Data[8] Measured value 1 [bit 0:7] Float 32 bit
Data[9] Measured value 1 [bit 8:15]
Data[10] Measured value 1 [bit 16:23]
Data[11] Measured value 1 [bit 24:31]
Data[12] Measured value 2 [bit 0:7] Float 32 bit
Data[13] Measured value 2 [bit 8:15]
Data[14] Measured value 2 [bit 16:23]
Data[15] Measured value 2 [bit 24:31]
Fig. 20 Encoding of Measured Data in the Transmission Protocol, INC5701S
