Page 7
Functional Principle, Technical Data
IF2030/ENETIP
2. Functional Principle, Technical Data
2.1 Functional Principle
The IF2030/ENETIP interface module is used to convert the internal Micro-Epsilon sensor protocol (RS485 or
RS422) to EtherNet/IP.
Features:
- LED status display
- EtherNet/IP interface
- Housing for top-hat rail
2.2 Technical Data
Model IF2030/ENETIP
Power supply +9 ... +36 V
Speed 1 ms refresh time, minimal
Power consumption (without sensor) approx. 2.5 W @24 V
Inputs
RS485 (ME protocol)
RS422 (ME protocol)
Outputs EtherNet/IP, sync output, LED status display
Temperature range
operation 0 ... +50 °C (+32 ... +122 °F)
storage -20 ... +70 °C (-4 ... +158 °F)
