MICRO-EPSILON IF2030/ENETIP - Class Directory

Page 20
Commissioning
IF2030/ENETIP
5.4 Class Directory
Class Instance Attribute Data type Name RS485 RS422 Description
0x80
1 0 Uint8 RW Select sensor Address of currently selected sensor
1 1 Uint8[32] R Sensor addresses Shows address list of available sensors
0x90 0 Uint32[64] R Device error log Reads out the last 32 error codes with time stamp
0xA0 1
0 Uint32 RW Baudrate IF2030 baud rate
1 Uint8 RW Minimum cycle time
Minimum time for one communication cycle in ms,
cycle time = 0: use estimated time
2 Uint8 RW
Preferred sensor
data size
Desired useful data length in bytes per sensor,
value = 0: estimated/calculated value
3 Uint8 RW Sensor interface
0: RS485,
1: Reserved,
2: ASCII + RS422
4 Uint8 W Reset device config
One byte deletes settings from flash, settings are
included in RAM until restart
5 Uint8 W Reset sensor config
One byte deletes settings from flash, settings are
included in RAM until restart
6 Uint8 W Reset device One byte performs reset
7 Uint8 RW
enable/disable
HTTL Sync
0: Disable HTTL synchronization
1: Enable HTTL synchronization
8 Uint8 RW
enable/disable cy-
clic status header
0: Disable 8 byte status header in cyclic data
1: Enable 8 byte status header in cyclic data
