Page 21
Commissioning
IF2030/ENETIP
Class Instance Attribute Data type Name RS485 RS422 Description
0x0310 1
Device Info Read out the block of the current sensor
0 Uint8 R Number of objects
1 Uint8 R Block version Block version
2 Uint8 R Endianness Endian
3 Uint16 R Software version Software version
4 Int32 R Article number Part number
5 Int32 R Option Option
6 Int32 R Batch number Batch number
7 Int32 R Serial number Serial number
8 Uint8 R Change index Change index
9 Uint8 R Calibration day Day of calibration
10 Uint8 R Calibration month Month of calibration
11 Uint8 R Calibration year Year of calibration
12 Uint16 R Calibration software version Version of calibration software
13 Uint16 R Test software version
14 Uint8 R Test hour
15 Uint8 R Test day
16 Uint8 R Test month
17 Uint8 R Test year
18 Int32 R Article number circuit board
19 Int32 R Serial number circuit board
20 Uint8[32] R Name
21 Uint8 R sensor/channel count
22 Uint8 R protocol block count
23 Uint8[164] R protocol blocks
