Page 11
Technical Data
thermoIMAGER TIM
2.2 Model Overview
The cameras of the TIM series are available in the following basic versions:
Model Type Temperature range Spectral range Frame rate Typical applications
TIM 160S IR -20 to 900 °C
200 to 1500 °C
(optional)
8 - 14 μm 120 Hz Surface measure-
ments in industrial
application
TIM QVGA /
TIM QVGA-HD
IR -20 to 900 °C
200 to 1500 °C
(optional)
8 - 14 μm 80 Hz Real-time thermo-
graphic images in
high speed; Detec-
tion of smallest tem-
perature differences
(TIM QVDA-HD)
TIM 640 VGA IR -20 to 900 °C
200 to 1500 °C
(optional)
8 - 14 μm 32 Hz Pin-sharp radiometric
recordings in real
time
TIM QVGA-G7 IR 200 to 1500 °C
150 to 900 °C
7.9 μm 80 Hz/ 27 Hz Measurement of
glass (with Line-
Scanning mode)
TIM VGA-G7 32 Hz
TIM M-1 IR 450 to 1800 °C 0.85 - 1.1 μm Up to 1 kHz Measurement of me-
tallic surfaces, graph-
ite or ceramics with
short wavelengths
TIM M-05 900 to 2450 °C 500 - 540 nm
