Technical Data
thermoIMAGER TIM
2.6 Measurement Specifications
Modell TIM 160S
Temperature range
(scalable)
-20 ... 100 °C; 0 ... 250 °C; 20 (150) ... 900 °C
1
;
additional temperature range: 200 … 1500 °C (optional)
Spectral range 8 - 14 μm
Detector UFPA
160 x 120 Pixel@120 Hz
Lenses (FOV) 12° x 9° FOV / f = 13 mm or
30° x 23° FOV / f = 5 mm or
55° x 40° FOV / f = 3 mm or
80° x 54° FOV / f = 2 mm
System accuracy
2
±2°C or ±2 %
Temperature
resolution (NETD)
3
80 mK with 30° FOV
100 mK with 55° and 80° FOV
300 mK with 12° FOV
Warm-up time 10 min
Emissivity 0.100 ... 1.100
Software TIMConnect
1) For the range (20) 150 up to 900 °C, the accuracy specification applies from 150 °C
2) At ambient temperature 23±5 °C; whichever is greater.
3) Values apply with 40 Hz and 25 °C room temperature
