MICRO-EPSILON thermoIMAGER TIM Series - 4.5 Microscope Optics TIM 640 VGA

Page 29
Optical Charts
thermoIMAGER TIM
4.5 Microscope Optics TIM 640 VGA
TIM 640 VGA
640 x 480 px
Focal length [mm] Angle Minimum measurment distance*
Distance to measurement object [m]
0.08 0.09 0.1
F44
Mikroscope optics
44.2
12°
9°
15°
0.36 mrad
0.08 m
HFOV [m]
VFOV [m]
DFOV [m]
IFOV [mm]
0.018
0.014
0.023
0.028
0.021
0.016
0.026
0.032
0.023
0.017
0.029
0.036
