Page 12
Technical Data
thermoIMAGER TIM
2.3 General Specifications
Model TIM 160S QVGA QVGA-HD QVGA-G7 640 VGA VGA G7 M-1 M-05
Protection class IP67 (NEMA-4)
1
Operating
temperature
0 ... 50 °C
(+32 ... +122 °F)
0 ... 70 °C
(+32 ... +158 °F)
0 ... 50 °C
(+32 ... +122 °F)
5 ... 50 °C
(+412 ... +122 °F)
Storage
temperature
-40 ... 70 °C
(-40 ... +158 °F)
-40 ... 85 °C
(-40 ... +185 °F)
-40 ... 70 °C
(-40 ... +158 °F)
Relative humidity 20 ... 80 %, con condensing
Material (housing) Aluminum, anodized
Dimensions 45 x 45 x
60 - 76 mm
(depending
on the lens
and focus
position)
46 x 56 x 68 - 77 mm
(depending on the lens and focus position)
TIM 640 VGA microscope optics:
46 x 56 x 119 - 126 mm
(depending on focus position)
46 x 56 x 76 - 100 mm
(depending on the
lens and focus posi-
tion)
46 x 56 x 88 - 129 mm
(depending on the lens
and focus position)
Weight
(inclusive lens)
195 g 237 - 252 g 269 - 320 g 245 - 311 g
Cable length (USB) 1 m (standard), 5 m, 10 m, 20 m
Vibration IEC 68-2-6: (sinus shaped), see 2.4
IEC 60068-2-64 (broadband noise), see 2.4
Shock IEC 68-2-27: 25 g and 50 g, see 2.4
1) Only with 5, 10, 20 m USB cable. The camera plug of USB cable (1 m) does not feature an IP67 protection class.
