Page 17
Technical Data
thermoIMAGER TIM
Model TIM QVGA QVGA-HD QVGA-G7
1
Temperature ranges
(scalable)
-20 ... 100 °C; 0 ... 250 °C; (20) 150 ... 900 °C
1
;
Option: 200 … 1500 °C
200 ... 1500 °C
150 ... 900 °C
Sighting range / low
energy range
2
- 0 ... 250 °C
Spectral range 8 - 14 μm 7.9 μm
Detector UFPA,
382 x 288 Pixel@80 Hz (switchable to 27 Hz)
Lenses (FOV) 18° x 14° / f = 20 mm or 29° x 22° / f = 12.7 mm or 53° x 38° / f = 7.7 mm or
80° x 54° / f = 5.7 mm
System accuracy
2
±2 °C or ±2 %
Temperature coef-
ficient
4
±0,05 %/K
Temperature resolution
(NETD)
75 mK
5
with 29°, 53° and
80°; 0.1 K
5
with 18°
40 mK
5
with 29°, 53° and
80°; 60 mK
5
with 18°
150 mK (T
obj
= 650 °C)
with 29°, 53°, 80°
175 mK (T
obj
= 650 °C)
with 18°
Warm-up time 10 min
Emissivity 0.100 ... 1.100
Software TIMConnect
1) Accuracy statement effective from 150 °C.
2) The sighting range is used to align the G7 cameras; at e < 1 and activation of the extended temperature
range a temperature measurement up to 1500 °C is possible.
3) At ambient temperature 23±5 °C; whichever is greater
4) For T
Amb
10 ... 50 °C und T
Obj
≤ 500 °C; otherwise ± 0,1 K/K or 0,1 %/K (whichever is greater)
5) Value is valid at 40 Hz and 25 °C room temperature
