Outputs and Inputs
thermoMETER CT
8.2.5 CAN BUS Interface
Mount the CAN BUS adapter, see Chap. 8.2.
i
Make sure the wiring is correct, see Fig. 39.
i
We recommend for industrial installations to connect the shield of the CAN BUS cable with the control-
ler housing (inside the cable gland).
The thermoMETER CT always needs an external power supply.
CAN Protocol
CAN open (see documentation on CompactConnect software CD)
Wiring
CAN Bus:
CAN_H on terminal „H“
CAN_L on terminal „L“
Analog signal:
Black cord on terminal „GND“
Red cord on terminal „OUT-mV“
The controller contains additional terminals to connect other devices (power supply, CAN bus, terminating
resistor).
