CAN module factory settings
Module address: 20 (14 H)
Baud rate: 250 kBaud
Analog input: 0 … 10 V
Temperature range: 0 … 60 °C (2 decimal places)
Emission ratio: 0.970
i
The settings for “Analog output 0 … 10 V“ and “Temperature range 0 … 60 °C” on the CT sensor must
be identical with the CAN bus module values.
Factory settings address and baud rate
CAN open service „LSS / Layer Setting Services“
Index temperature value:
The temperature information is located in the object register 7130h (Sub01):
e.g. B4: LB
B4: DA
B5: HB
B5: 07 T = 20.10 °C
Before delivery, MICRO-EPSILON can set parameters, desired by the customer, for an extra charge. For the
subsequent conversion a CAN master is required.
Diagnosis
If the power supply is on, the LED displays one of the following conditions:
State Meaning
Flashes quickly
Device is in preoperational
mode.
Off Power supply is not correct / faulty hardware.
Illuminates Device is in operational mode.
Sparkles Device is stopped. = Communication stopped.
