Page 59
Outputs and Inputs
thermoMETER CT
8.2.6 Ethernet Interface
8.2.6.1 Installation
Mount the Ethernet adapter, see Chap. 8.2.
In case you want to run the pre-mounted cable of the Ethernet box through the delivered cable gland,
the terminal block has to be disassembled/assembled.
The thermoMETER CT always requires an external power supply of at least 12 V.
i
Make sure the wiring is correct according to the colors printed on the interface board.
Please connect the shield of the cable with the controller housing (inside the cable gland).
Please connect the Ethernet adapter device with your network using an Ethernet cable.
