3. Video Compression Type: Selectable options : H264/M-JEPG / MPEG-4
4. Resolution: Selectable Options: D1/CIF /QCIF
5. Bit rate Type: There are two selectable options: constant bit rates (CBR)
and variable bit rates (VBR), providing the flexibility in choosing
bandwidth.
6. Constant bit rates (CBR): 4M / 3M / 2M / 1.5M / 1M / 750K / 500K / 384K
/ 256K / 128K / 64K
Note: 1M is recommended when using H.264; 1.5M is recommended when
using MPEG-4.
Note: When mosaic or fragment occurs in the image, users may lower the
frame rate or assign another level of image quality.
7. Variable bit rates (VBR) ranges: 15 ~ 51 (The value “15” is
recommended.)
8. Frame per second: 1 / 5 / 10 / 15 / 20 / 25 / 30
9. Group Size （GOP）: This function is designed for adjusting the ratio
between “I” frame and “P” frame. Lower the group size represents the
lower bandwidth consumption.
10.Video Type: NTSC / PAL
Note: System can automatically detect the input video signal when the
detect icon clicked.
Æ Max Client
This function allows more than one user to have the access to the video
stream. The relationship between bit rates, resolution, and the client
