A: Specification
36 Portaflow 220 User Manual
(Issue 1.0)
LANGUAGES
Standard Supported Languages: English, French, German, Italian, Spanish, Portuguese, Russian, Norwegian, Dutch.
OUTPUTS
Analogue Output:
Resolution:
Alarm Currents:
Isolation:
Maximum Load:
4–20mA, 0–20mA, 0–16mA.
0.1% of full scale.
Any between 0–26mA.
1500V Opto-isolated.
620 Ohms.
Pulse Output TTL:
Pulse Repetition Rate:
Pulse Width:
Max Current:
Number Available: One open collector opto-isolated digital output.
Up to 500 pulses/sec (depending on pulse width).
500ms for 1pulse/sec.
5ms for 100 pulses/sec.
150mA.
ELECTRICAL
Supply Voltage:
Input Voltage Range: 9–24Vdc.
Power Consumption: 10.5W.
Battery:
Technology: 5-cell NiMH.
Capacity: 3.8AHr.
Operating Time: Typically 20 hours continuous with backlight and 4-20mA output OFF.
Recharge Time: 6.5 Hours.
Service Life: >500 charge/discharge cycles.
Power Supply/Charger:
Manufacturer: ECOPAC Model ECO-181WP12.
Input Voltage Range: 90–264Vac.
Input Frequency Range: 47–63Hz.
Output Voltage: 12Vdc.
Max. Output Current: 1.5A.
Approvals: UL, CUL, TUV, CB & CE.
MECHANICAL
Carrying case:
Rating: All components are contained in a hard-wearing polyproylene carrying case with a
protective moulded foam insert.
Enclosure:
Material: Flame retardant injection moulded ABS.
Dimensions: 264mm x 168mm x 50mm.
Weight (Including Battery): 1.1 kg.
Protection: IP54.
