1: General Description
Portaflow 220 User Manual 3
(Issue 1.0)
1.3 Supplied Hardware
The Portaflow equipment is supplied in a rugged polypropylene carrying case fitted with a foam insert to give
added protection for transportation. The supplied components are shown in Figure 1.2.
Figure 1.2 Standard Portaflow equipment
Standard equipment
• Portaflow 220 instrument with backlit graphic display.
• Power supply - with UK, US, European adaptors. 110/240VAC.
• 4-20mA/Pulse Output cable, USB cable and RS232-C cable.
• 2 lengths of chain.
• Test block.
• Transducer cables (x2) 2 metres long (one red and one blue).
• Transducer set (x2) – type ‘A’ or type ‘B’ depending on model.
• Set of guide rails used for mounting the transducers.
• Ruled separation bar (2-piece).
• Ultrasonic couplant with syringe dispenser used when mounting the transducers.
• Manual (on CD).
