Portaflow 220 User Manual 35
(Issue 1.0)
Appendix A: Specification
GENERAL
NEW! DSP Measurement Technique: Transit time.
Timing Resolution: 50 pico-seconds, continuous signal level indication on display.
Improved! Flow Velocity Range: Minimum Velocity 0.1m/s; Max Velocity 20m/s: Bi-directional.
Turn Down Ratio: 100:1
Accuracy: ±0.5% to ±2% of flow reading for flow rate >0.2m/s and Pipe ID >75mm.
±3% of flow reading for flow rate >0.2m/s and Pipe ID in range 13mm - 75mm.
±6% of flow reading for flow rate < 0.2m/s.
Repeatability: ±0.5% of measured value or ±0.02m/s whichever is the greater.
NEW! Reynolds Number Correction: Flow velocity corrected for Reynolds number over entire velocity range.
Response Time: < 500ms depending on pipe diameter.
Selectable Flow Units: VELOCITY: m/sec, ft/sec.
VOLUME: l/s, l/min, l/h, gal/min, gal/h, USgals/min, USgals/h, Barrel/h, Barrel/day, m³/s,
m³/min, m³/h.
Selectable Volume Units: l, gal, USgals, Barrel, m³.
Total Volume: 12 Digits - forward and reverse.
APPLICABLE FLUID TYPES
Fluid Condition: Clean liquids or oils that have less than 3% by volume of particulate content. Applications
include river water, sea water, potable water, demineralised water, glycol/water mix,
hydraulic systems and diesel oil.
APPLICABLE PIPE TYPES
Pipe Materials: Any sonic conducting medium such as Carbon Steel, Stainless Steel, Copper, UPVC, PVDF,
Concrete, Galvanised Steel, Mild Steel, Glass, Brass. Including Lined Pipes - Epoxy,
Rubber, Steel, Plastic.
Pipe Dimension (outside diameter): PF220A 13mm – 115mm.
PF220B 50mm – 1000mm.
Pipe Wall Thickness: 1mm - 75mm.
Pipe Lining: Applicable pipe linings include Rubber, Glass, Concrete, Epoxy, Steel.
Pipe Lining Thickness: 0mm – 10mm.
Pipe Wall Temperature Range: Sensor operating temperature is -20°C to +135°C.
TRANSDUCER SETS
Standard transducers: Temperature Range -20°C to +135°C.
PF220A – Type 'A-ST' (2MHz).
PF220B – Type 'B-ST' (1MHz).
