Saving Images and Records
The Part Queue
4
v4.1.3, April 2012 Visionscape FrontRunner™ User’s Manual 4-9
Saving Current Image from the Part Queue
Use the following procedure to save the current image from the Part
Queue:
1. From the Save drop down menu, click Save Current Image (TIF), as
shown in Figure 4–9.
FIGURE 4–9. Save Current Image
FrontRunner™ saves the image in the Jobs folder using the naming
convention:
Inspection_CycleNumber_SnapshotNumber.tif
Saving All Images from the Part Queue
Use the following procedure to save all images from the Part Queue:
1. From the Save drop down menu, click Save All Images (TIF), as
shown in Figure 4–10.
