DOC 6501_Release V
ATS-6501 Users Guide
3
13. 4387A-6V Four 6V Modulated IRIG Outputs (Default Timecode = B120) or
NASA36
14. 4396A/4397A Four 2.048MHz (E1) outputs that comply with ITU-T Rec. G.703
15. 4372A-T Four input/output single mode fiber optic module for supplying signals to a
TSC-4340 or ATS-6511
16. 4393A Four Channel TIC Card. Users can measure the 1PPS of up to four different
devices relative to the internal clock and obtain these measurement results in real
time.
17. 4383A IRIG Input Card. Users can set the system time manually using an IRIG Time
Source. Ports 1 and 2 support DC IRIG and Ports 3 and 4 support AM IRIG.
Options:
94000-115200 USB Console Cable: Allows users to connect to the system Command Port
via a serial cable. Formerly P/N OP001
94001-5071A USB External Reference Communication Cable: Provides a serial
communications port to an external frequency reference (i.e. 5071A). Formerly P/N OP002
TSC-4340AS-8S: 1 U fiber expansion chassis with single mode input and 8 single mode
outputs.
TSC-4340AM-8M: 1 U fiber expansion chassis with one multimode mode input and 8 multi-
mode outputs.
Notes:
1. The correct Microsemi part number is constructed by appending the desired options to the base model in
alphabetical order. None of the options are mutually exclusive so users can select as many options as
desired.
Example Part Number: ATS-6501-DFR
Description: Tflex with 1 AC input and 1 DC input option, front panel memory option, and internal
rubidium clock reference option.
2. Antenna cables sold separately.
3. All units include an L1/L2 antenna, network time protocol (NTP), 94000-115200 (RS232 console
cable), Ethernet control, and data logging capabilities.
4. Contact Microsemi (www.microsemi.com) for current pricing and availability.
5. 94000-115200 and 94001-5071A are DTE devices; this may require the use of a null modem serial
cable.
