DOC 6501_Release V
ATS-6501 Users Guide
202
Type Model Description
25 TSC4351 TCT Fiber Output Module
26 TSC4352 TCT Fiber Input Module
40 4307 Blank module cover
41 4372A/4372A-T 4-port fiber distribution module
42 4385A 6501/6511AC Power Supply
43 4385B 6501/6511AC Power Supply
44 4386A 6501/6511 DC Power Supply
45 4387A 4-port IRIG output module
46 4387A_6V 4-port 6-volt output module
47 4393A 4-port 1 PPS input measurement module
48 4394A 4-port PPS or DC IRIG output module
49 4395A_1 4-port 1 MHz output module
50 4395A_5 4-port 5 MHz output module
51 4395A_10 4-port 10 MHz output module
52 4395B_1 4-port 1 MHz output module
53 4395B_5 4-port 5 MHz output module
54 4395B_10 4-port 10 MHz output module
55 4399A L-band module (2-slot, 6511 only)
56 4372-O One Way Fiber Card (Legacy Fiber)
57 4391A Code Generator
58 4394A-ECL PPS Card (ECL)
59 4374A T1 Card
60 4387A-1V AM IRIG w/1V RMS Output
61 4376A RS-422 PPS Card
62 4383A IRIG Input Card
63 4337A AM IRIG Epoch Module
Table 12 Child Node Types
Type Model Description
14 TSC2007 Obsolete
15 2000 Series SONET Chassis (TSC2078 CPU) Modular backplane
70 TSC2002 Blank module
71 TSC2024 Chassis monitor
72 TSC2030 1x4 RF Dist Amp
73 TSC2031 RF Doubler 5/10MHz
74 TSC2032 Pulse distribution amplifier
75 TSC2034 RF distribution amplifier
76 TSC2035 1x4 Variable Gain Dist Amp
77 TSC2036 RF distribution amplifier
78 TSC2042 Quartz Oscaillator
79 TSC2043 DDS
80 TSC2045 5MHz Clean Up Oscillator
81 TSC2055 Time Code Generator
82 TSC2057 IRIG-B/2137 Code Generator
83 TSC2058 Precision Timer
84 TSC2059 LF Distribution amplifier
85 TSC2061 Synchronizable Divider
86 TSC2062 1MHZ to PPS Divider
87 TSC2091 RF fault/sense switch
88 TSC2092 IRIG fault/sense switch
89 TSC2093 PPS fault/sense switch
90 TSC2094 ECL PPS fault/sense switch
91 TSC2130 42 Bit Parallel Time Code Generator
92 TSC2132 TTl/ECL Converter
