IM 613 / Page 3 (Rev. 7/99)
This manual provides information pertaining to the
MicroTech Unit Ventilator Controller (UVC) as applied in the
AAF-HermanNelson Unit Ventilator product line. It should be used
in conjunction with the separate installation (Bulletin
No. OM101 through OM107) and sequence of operation
literature (see Tables 5 and 6).
CAUTION
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. It has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a residential environment. AAF-HermanNelson
disclaims any liability resulting from any interference or for the correction thereof.
CAUTION
This MicroTech controller contains static electricity sensitive components. A static discharge while handling electronic
circuit boards may cause damage to the components. To prevent such damage during service involving board replacement,
discharge any static charge by touching grounded bare metal inside the unit before performing any service work.
WARNING
If the unit ventilator is to be used for temporary heating or cooling, the unit must first be properly commissioned. Failure to
comply with this requirement will void the warranty.
WARNING
This MicroTech control panel is designed to be stored and operated in temperatures from 32°F to 140°F and in relative
humidity up to 95% (noncondensing).
Introduction
