IM 613 / Page 4 (Rev. 7/99)
Figure 1. MicroTech Unit Ventilator Controller
COMMB COMM A DIGITAL INPUT
GGGGGGS S S S S S GSGS
IN2
IN3IN4IN5IN6IN7IN12IN13
GS1SO
100
0
10
20
30 40
50
75
10
5
15
0
20
65
85
75
70
80
MINIMUM OA
POSITION
UNOCCUPIED
OFFSET
HEATING SETPOINT
(COOLING SETPOINT IS
FACTORY SET 6° F ABOVE
HEATING SETPOINT)
NETWORK
ADDRESS
HI LO
This device complies with part 15 of the FCC rules.
Operation is subject to the following 2 conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including
interference that may cause undesired operation.
SERIAL
EOS
PROG
LED
GO
RELAY OUT
H12345678
AUX OUT
V910
PWR
G 24V
STATUS POWER
STATUS POWER
J1
J5
J4
J3
J2
J6
J7 J8
J9
%
°F
MicroTech
®
325 Controller
PART NO. 107627201
1 2 3
1 2 3 4 5 6 R 5 4
Remote Status
LED Output
Relay Outputs
Auxiliary
Outputs
(TRIAC)
Status LED
Power Supply LED
Software ID tag
Electro-Mechanical
Relays
Hex Switches
Digital Inputs
Communication
Ports
Analog Inputs
Heating
Setpoint Pot
Minimum OA
Damper
Position Pot
Unoccupied
Offset Pot
65
70
8060
75
EOS + S/N tag
General Description
Component Data
The MicroTech Unit Ventilator Controller (UVC) is a microproces-
sor-based controller designed to provide sophisticated control of
an economizer-equipped AAF-HermanNelson unit ventilator. In
addition to providing normal operating control, the MicroTech UVC
provides alarm monitoring and alarm-specific component
shutdown if critical system conditions occur.
Each UVC is factory wired and factory programmed for the spe-
cific unit ventilator model and configuration options ordered by
the customer. The UVC can be wired and programmed to oper-
ate as a stand-alone controller, as a master or slave
controller, or as a MicroTech network controller.
Communication ports allow networking capability and
access to any UVC from an IBM compatible personal computer
(PC) equipped with Monitor software.
The MicroTech Unit Ventilator Controller (UVC) is shown in
Figure 1.
