Certified Drawing
IM 613 / Page 31 (Rev. 7/99)
Parts List
➀
➁
Notes:
1. This is a partial listing of the unit ventilator replacement parts. Contact your local representative for additional information.
2. The MicroTech UVC part order must include the job control number, full unit model number, and serial number so that the proper
software can be factory loaded. These numbers are listed on the unit data plate.
Symbol Description Part No.
UVC MicroTech Unit Ventilator Controller 073397901
S1 Room temperature sensor, unit mounted GEF1947
S1 Room temperature sensor, wall mounted 4EZS9315
S1 Room sensor with tenant override, wall mounted 4EZS9316
S1 Room sensor with remote setpoint adjust, wall mounted 4EZS9317
S1 Room sensor with tenant override & remote setpoint adjust, wall mounted 4EZS9318
S1 Room temperature sensor with thermometer, wall mounted 4EZS9319
S1 Room sensor with tenant override & thermometer, wall mounted 4EZS9320
S1 Room sensor with remote setpoint adjust & thermometer,wall mounted 4EZS9321
S1 Room sensor with tenant override, remote setpoint adjust & thermometer, wall mounted 4EZS9322
S2 Discharge air temperature sensor GEF1947
S3 Outdoor air temperature sensor GEF1948
S4 Mixed air temperature sensor GEF1945
S5 Water-in temperature sensor GEF1948
S6 Water-out temperature sensor GEF1948
SW3 Tenant override switch, unit mounted 4EAL7261
SW4 Day-night switch 4EAL7759
SW6 Holiday switch 4EAL7759
R4 Fan relay 4EWJ8505
X2 Transformer (120/24 VAC) 4EPC8561
X2 Transformer (208, 230, 460/24 VAC) 4EPC9174
X2 Transformer (277/24 VAC) 4EPC7997
X3 Transformer (120/24 VAC) 4EPC9175
X3 Transformer (208, 230/24 VAC) 4EPC9176
X3 Transformer (277, 460/24 VAC) 4EPC9177
T4 Low temperature switch, DX coil 4ELN7604
T6 Low temperature switch, hydronic coil 4ELN9178
HP High pressure switch 4EMB8937
A1 Damper actuator, outdoor air 4EZB9324
A2 Damper actuator, face-and-bypass 4EZB9324
V1 Valve actuator, heating valve (body not included) MF5513
V2 Valve actuator, chilled water valve (body included) MF5513
-- IDC style connector, 2 terminal 4EGA9159
-- IDC style connector, 3 terminal 4EGA9160
-- IDC style connector, 4 terminal 4EGA9161
-- IDC style connector, 5 terminal 4EGA9162
-- IDC style connector, 6 terminal 4EGA9163
-- PC communications cable kit 57186801
9. Watch memory location 0507 change, when this value stops
changing, the OA damper should be fully opened. On a
sheet of paper, write this value down for later use.
10. Write a 0 to location 0214. Then write a 255 to location
0215, this will return a value of 1. This will begin closing the
OA damper.
11. Watch memory location 0507 change, when this value stops
changing, the OA damper is fully closed. On a sheet of pa-
per, write this value down for later use.
12. Write a 0 to location 0215.
13. Using the Read/Write screen write the lowest value of the
two numbers you wrote down on the sheet of paper to
location 0901, then write the higher value to location 0902.
14. Change location 0A01 to match 0A02.
15. Reset the controller by writing 4 to location 0204.
16. The controller should start its program and begin
operating normally.
Note: The same procedure is used for MicroTech 125
controllers except you replace all instances of 0A01 with
8001, and replace all instances of 0A02 with 8002.
