Flooded type water cooled screw chiller (PCB Control) MCAC-CTSM-2012-11
85
Appendix 1: R134a saturation temperature - pressure corresponding tables
Note: this table of pressure values for absolute pressure value, the pressure value ( unit touch screen
display value ) for the vast pressure value and the local atmospheric pressure difference.
Appendix 2: the flow chart of the system
R134a saturation temperature - pressure corresponding tables
℃ KPa ℃ KPa ℃ KPa ℃ KPa
-15 164 7 375 29 748 51 1351
-14 171 8 388 30 770 52 1385
-13 178 9 401 31 793 53 1420
-12 185 10 415 32 815 54 1455
-11 193 11 429 33 839 55 1492
-10 201 12 443 34 863 56 1528
-9 209 13 458 35 887 57 1566
-8 217 14 473 36 912 58 1604
-7 225 15 488 37 937 59 1642
-6 234 16 504 38 963 60 1682
-5 243 17 521 39 990 61 1722
-4 253 18 537 40 1017 62 1763
-3 262 19 554 41 1044 63 1804
-2 272 20 572 42 1072 64 1847
-1 282 21 590 43 1101 65 1890
0 293 22 608 44 1130 66 1934
1 304 23 627 45 1160 67 1978
2 315 24 646 46 1190 68 2024
3 326 25 665 47 1221 69 2070
4 338 26 685 48 1253 70 2117
5 350 27 706 49 1285 71 2165
6 362 28 727 50 1318 72 2213
