Not drying (gas model) - Poor gas ignition
When dryer is operated in a heat setting, the igniter is energized at 120 VAC and flame appears in
the burner within 45 seconds. Failure of any component in this system is usually indicated by one of
the three symptoms given below:
1) Igniter does not sp ark
Turn off power supply.
Using an ohmmeter, check the following.
Replace motor.
No
Check resistance of igniter.
Is resistace in range?
Yes
Replace igniter.
Check regulating thermostat. Does it show
continuity?
Replace regulating thermostat.
No
No
Yes
Yes
Check hi-limit thermostat on heater. Does it
show continuity?
No
Replace heater assembly.
Does wiring show continuity?
Replace harness.
No
Does flame switch show continuity?
Replace flame switch.
Yes
Check centrifugal switch (motor).
Does it show continuity?
Replace PCB.
Yes
Yes
No
