Service manual for Dryer Machine Midea America Company
-------------------------------------------------------------------------------------------------------------------------------------------------------
－ 42 －
25(a). Remove the back
cover (Electric model)
25.1 Remove 1 screw on
the back cover;
25.2 Remove 2 screws
that is used to fix power
line;
25.3 Remove 12 screws
that is used to fix back
cover;
25.4 Take down the back
cover.
25(b). Remove the back
cover (Gas model)
25.1 Pull out two terminals;
25.2 Remove 12 screws
on the back cover;
25.3 Take down the back
cover.
26. Remove 4 screws to
take down the air flue
assembly.
①
①
Take down the back cover
③
②
③
③
②
②
Take down the back cover
②
