Midea MDH210-V042/B01EHS-US User Manual

Service manual for Dryer Machine Midea America Company
-------------------------------------------------------------------------------------------------------------------------------------------------------
－ 43 －
27. Remove the rear
support assembly
27.1 Remove 4 screws on
the rear support.
27.2 Take down the rear
support.
28. Remove the burner
assy (Gas model only)
28.1 Pull out 4 terminals of
thermostats;
28.2 Pull out the terminal
of harness;
28.3 Remove 4 screws
fixing the burner assy.
28.4 Take down the burner
assembly.
29. Remove 4 screws to
take down thermostats
(Gas model only)
①
②
③
④
②
③
①
