Midea MGBT-F30W/RN1 User Manual

MCAC-ATSM-2014-09 Aqua tempo power series tropical air-cooled scroll chiller 50Hz
131
6
Software configuration
● LonMark standard allocative attribute
● Support Direct-Memory reading and writing by the LNS network
management tool.
7
Communication port
Communication port
8
Size
31.9cm X 25.1cm X 6.1cm
2.9.4 External dimension
There are three installation methods as the following figure. Do not install the unit in any other orientation
291
319
251
268.8
61
15
22
2.9.5 Connection Method
Connection Method 1
Air-cooled Modular units:Max 16 units
LONWORKS
NET WORK
LSQ-LONWORKS
BMS SYSTEM
RS485(P Q E)
Air cooled scroll chiller: max. 16 units

Midea MGBT-F30W/RN1 Specifications

General

Brand	Midea
Model	MGBT-F30W/RN1
Category	Chiller
Language	English
