Aqua tempo power series tropical air-cooled scroll chiller 50Hz MCAC-ATSM-2014-09
26
2. Pipe connection drawing
2.1MGBT-F25W/RN1,MGBT-D25W/RN1,MGBT-F30W/RN1,MGBT-D30W/RN1
The table below describes the symbols.
Symbol
Symbol explanation
Symbol
Symbol explanation
Stop valve
Y-shaped filter
Pressure gauge
Thermometer
Water flow switch
Circulating pump
Gate valve
Check valve
Flexible joint
Automatic discharge valve
