1.8 Specification: MGBT-F60W/RN1, MGBT-D60W/RN1, MGBT-F120W/RN1
Model
MGBT-F60W/RN1
MGBT-D60W/RN1
MGBT-F120W/RN1
Cooling Capacity (*1)
kW
60
120
Btu/h
204,700
409,400
Cooling Capacity (*2)
kW
51.6
103.2
Btu/h
176,100
352,100
Heating Capacity
kW
64
65
128
EER(*1)
kW/ kW
3.11
3.09
3.12
EER(*2)
kW/ kW
2.20
2.22
2.23
COP
kW/ kW
3.23
3.19
3.08
Power supply
V/Ph/Hz
380~415/3/50
Power supply
Manual switch
A
100
200
Fuse
A
70
150
Compressor
Type
Scroll (fixed speed)
Digital Scroll + Fixed
speed
Scroll (fixed speed)
Brand
Copeland
Copeland
Copeland
Model
ZP137KCE-TFD-522
ZP137KCE-TFD-522
/ZPD72KCE-TFD-433
/ ZP67KCE-TFD-420
ZP137KCE-TFD-522
Quantity
Pieces
2
1+1+1
4
Power input
Cooling (*1)
kW
19.3
19.4
38.5
Cooling rated current (*1)
A
33.6
33.6
68.8
Cooling (*2)
kW
23.16
23.28
46.2
Cooling rated current (*2)
A
40.32
40.32
82.56
Heating
kW
19.8
20.4
41.5
Heating rated current
A
34.3
35.1
71.8
Max. Input consumption
kW
29.5
29
55.5
Rated Current
A
51.5
51.5
130
Refrigerant
Type
R410A
R410A
R410A
Refrigerant control
EXV+ capillary
Weight
kg
6.0×2
6.5×2
6.0×4
Condenser
(Air side)
Air side heat-exchanger type
Fin-coil
Quantity of fan motor
Pieces
2
2
4
Air flow volume
×10
3
m
3
/h
24
24
48
Fan motor model
YS700-6F
YDK550-6E
YS700-6F
Fan motor rated current
A
1.8×2
4.0×2
1.8×4
Fan motor input
kW
0.9×2
0.865×2
0.9×4
Evaporator
(Water side)
Water side heat-exchanger type
Shell and tube
Shell and tube
Shell and tube
Water pressure drop
kPa
15
15
25
Volume
L
42
42
64
Water inlet/outlet pipeline
inside normal diameter
mm
DN100
DN100
DN65
inch
4”
4”
2-1/2”
Water flow volume
m
3
/h
10.3
10.3
22.4
Max. Pressure
MPa
1
1
1
Evaporator volume
L
42
42
46
Water pipe connection type
Flexible joint
Flexible joint
Flexible joint
Dimension
Net(W×H×D)
mm
2000×1880×900
2000×1880×900
2000×1685×2090
