Aqua tempo power series tropical air-cooled scroll chiller 50Hz MCAC-ATSM-2014-09
50
No.
Part Name
Qty
No.
Part Name
Qty
20
Ass'y B of left seal plate,condenser
1
48
Wired controller
1
21
Accumulator cylinder
2
49
Total water temperature mouth components
1
22
Base
1
50
EXV solenoid
2
23
Base ass'y
1
51
Pipe temperature sensor ass'y
2
24
Electronic control box assembly of Air-cooled
module
1
52
Pipe temperature sensor ass'y
4
24.1
Welding together pieces of electronic control box
1
53
Room temp. sensor ass'y
1
24.2
Mounting plate with pieces of electrical
1
54
Discharge temperature sensor
2
24.3
30KW Air-cooled module control board
assembly
1
55
Pressure controller
2
24.4
Relay
2
56
Pressure controller
2
24.5
Contactor
2
