Midea MGBT-F30W/RN1 User Manual

MCAC-ATSM-2014-09 Aqua tempo power series tropical air-cooled scroll chiller 50Hz
11
1.7 Specification: MGBT-F30W/RN1, MGBT-D30W/RN1
Model
MGBT-F30W/RN1
MGBT-D30W/RN1
Cooling Capacity (*1)
kW
30
Btu/h
102,300
Cooling Capacity (*2)
kW
25.8
Btu/h
88,030
Heating Capacity
kW
32
EER(*1)
kW/ kW
3.00
EER(*2)
kW/ kW
2.15
COP
kW/ kW
3.27
Power supply
V/Ph/Hz
380~415/3/50
Power supply
Manual switch
A
50
Fuse
A
36
Compressor
Type
Scroll (fixed speed)
Digital Scroll + Fixed speed
Brand
Copeland
Copeland
Model
ZP61KCE-TFD-522
ZPD61KCE-TFD-532/
ZP61KCE-TFD-522
Quantity
Pieces
1+1
1+1
Power input
Cooling (*1)
kW
10.0
Cooling rated current (*1)
A
16.3
Cooling (*2)
kW
12
Cooling rated current (*2)
A
19.56
Heating
kW
9.8
Heating rated current
A
16.0
Max. Input consumption
kW
12.6
12.5
Rated Current
A
21.1
21.1
Refrigerant
Type
R410A
Refrigerant control
EXV
Weight
kg
3.1×2
Condenser
(Air side)
Air side heat-exchanger type
Fin-coil
Quantity of fan motor
Pieces
1
Air flow volume
×10
3
m
3
/h
12
Fan motor model
YDK400-8-YA
Fan motor rated current
A
2.95
Fan motor input
kW
0.65
Evaporator
(Water side)
Water side heat-exchanger type
Double-pipe
Water pressure drop
kPa
60
Volume
L
10
Water inlet/outlet pipeline
inside normal diameter
mm
DN40
inch
1-1/2”
Water flow volume
m
3
/h
5.2
Max. Pressure
MPa
1
Evaporator volume
L
10
Water pipe connection type
Flexible joint
Dimension
Net(W×H×D)
mm
1514×1865×841
inch
59.6×73.4×33.1
