Aqua tempo power series tropical air-cooled scroll chiller 50Hz MCAC-ATSM-2014-09
16
Packing size(W×H×D)
mm
2980×2135×2260
3900×2200×2100
inch
117.3×84.1×89
153.54×86.61×82.68
Weight
Net weight
kg
1730
2450
Gross weight
kg
1780
2500
Connection wire
Power wire
mm
2
×No.
70×3+35×2
185×4+70×1
Signal wire
mm
2
×No.
0.75×3-core with shielding
0.75×3-core with shielding
Control type
Wired controller
Wired controller
Wired controller
Safety protection device
1) Protection for over-high discharge pressure.
2) Protection for over-low suction pressure.
3) Power supply phase sequence protection.
4) Anti-frozen protection in cooling mode.
5) Anti-frozen protection in Winter.
6) Protection for compressor over current.
7) Protection for compressor overload.
8) Outlet and inlet water temp. difference protection.
9) Compressor discharge temp. protection.
10) Water flow cut-off protection.
11) Sensor malfunction protection.
12)Low-temp. protection of shell-and-tube heat exchanger.
Sound level(semi-anechoic )
dB(A)
74
74
Operation water temp.
℃
Cooling：5～17
Heating：45～50
Cooling：0～17(5℃ must
add antifreeze)
Heating：22～50
Ambient temp.
℃
Cooling：10～52
Heating：-10～21
Cooling：10～52
Heating：-10～21
Note: Specifications are based on the following conditions:
Cooling : (*1) chilled water inlet/outlet: 12˚C / 7˚C, and outdoor ambient temp. of 35°C (117℉) DB.
(*2) chilled water inlet/outlet: 12˚C / 7˚C, and outdoor ambient temp. of 46˚C (140℉)DB
Heating : warm water inlet/outlet: 40˚C / 45˚C, and outdoor ambient temp. 7˚C DB/6°CWB.
Water side fouling factor: 0.086m
2
˚C /kW.
