Midea MGBT-F30W/RN1 User Manual

Aqua tempo power series tropical air-cooled scroll chiller 50Hz MCAC-ATSM-2014-09
64
No.
Part Name
Qty
No.
Part Name
Qty
1
A combination of pieces of fixed plate condenser
1
27
Electrical box door
1
2
Condenser side board
2
28
A machine back to the tube components
1
3
Condenser ass'y A
1
29
A machine back to the tube ass'y
1
3.1
Condenser ass'y of A
1
30
A four-way valve assembly machine
1
4
Condenser ass'y B
1
30.1
4-way valve
1
4.1
Condenser ass'y of B
1
30.2
Pressure controller
1
5
Middle beam
2
30.3
Pressure controller
1
6
Fixed board
2
31
Four-way valve ass'y of A
1
7
Mid upright support
2
31.1
4-way valve
1
8
Pipe fixing clamp
2
31.2
Pressure controller
1
9
Evaporator input pipe ass'y
1
31.3
Pressure controller
1
9.1
Electronic expansion valve
1
32
Drainage pan ass'y
1
10
Evaporator input pipe ass'y
1
33
Middle partition plate
2
10.1
Electronic expansion valve
1
34
Net
2
11
Cover
1
35
Net
4
12
Cover
1
36
Top upright support
2
13
Triangle reinforcement ass'y
8
37
Condenser seal connector
1
14
Reinforcement board
4
38
Top cover
2
15
Base
1
39
Axial flow fan
2
16
Supporting ass'y of compressor
2
40
A unit discharging pipe ass'y
1
17
Cover
1
41
Motor
2
18
Wiring terminal fixing board
1
42
Mid horizontal support
2
19
Cover
1
43
Motor bracket ass'y
4
20
Cover
1
44
Condenser seal connector
1
21
Outdoor unit electrical box ass'y
1
45
Unload valve ass'y
1
21.1
Electrcial box welding part
1
46
Fixed plate with the condenser B
1
21.2
Outdoor main board ass'y
1
47
EEV solenoid coil
2
21.3
Contactor
2
48
Discharge temp sensor
3
21.4
Outdoor unit currrent detection ass'y
1
49
Room temp sensor ass'y T41
1
21.5
Wire joint,11p
1
50
Coil temp. sensor ass'y
2
21.6
Wire joint,4p
1
51
Temp.sensor ass'y
1
21.7
Capacitor
2
52
Coil temp sensor ass'y
3
21.9
Terminal block
3
53
Compressor electric heater
1
21.10
Wire joint
1
55
4-Ways valve solenoid
2
21.11
Transformer
1
56
Refrigerant
13
21.12
Relay
3
57
Compressor
1
21.13
AC contactor
1
58
Compressor
1
22
Wire Groove
0.5
59
Compressor
1
23
Vapor-liquid separator
2
60
Gas balance pipe of compreesor
1
24
Shell and tube evaporator
1
61
Oil balance pipe ass'y
1
25
Cover
1
62
Total water temperature mouth components
1
26
Pole
4
63
Accessory- wired controller(English)
1
