MCAC-VTSM-2015-09 R410A All DC Inverter V4+S Series 60Hz
Specifications & Performances 23
Combination unit specifications
50~130% of outdoor unit capacity
(960×1615×765)+(1250×1615×765)
(1025×1790×830)+(1305×1790×820)
Operating temperature range
Cooling: -5-48(23~118.4); Heating: -20-24(-4~75.2)
Notes:
Capacities are based on the following conditions:
Cooling: Indoor temperature 27
o
C DB/19
o
C WB; Outdoor temperature 35
o
C DB/24
o
C WB;
Heating: Indoor temperature 20
o
C DB/15
o
C WB; Outdoor temperature 7
o
C DB/6
o
C WB.
Piping length: Interconnecting piping length is 7.5m, level difference is zero.
Connection piping diameter of single-unit is the stop valve diameter of the unit.
Connection piping diameter of multi-unit is the main pipe connecting to the first indoor branch joint, is case of the total equivalent liquid length is
less than 90m. If the total equivalent liquid length is more than 90m, please refer to technical manual to choose the connection piping diameter.
Sound values are measured in a semi-anechoic room, at a position of 1m in front of the unit and 1.3m above the floor.
