7. Capacity tables
7.1 Cooling capacity tables
8HP CR: Combination Ratio; TC: Total Capacity (kW); PI: Power Input (kW) (Compressor + Outdoor fan motor)
CR
Outdoor
temp.
(°C DB)
Indoor temperature(°C DB/WD)
20.8/14
23.3/16
25.8/18
27/19
28.2/20
30.7/22
32/24
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
130%
-5
22.1
2.40
26.4
2.93
30.6
3.14
31.8
3.27
33.3
3.36
34.1
3.66
35.0
3.68
-2
22.1
2.40
26.4
2.99
30.6
3.14
31.8
3.29
33.3
3.36
34.1
3.70
35.0
3.72
0
22.1
2.44
26.4
3.04
30.6
3.26
31.8
3.47
33.3
3.56
34.1
3.75
35.0
3.77
2
22.1
2.49
26.4
3.05
30.6
3.37
31.8
3.66
33.3
3.60
34.1
3.78
35.0
3.82
4
22.1
2.54
26.4
3.11
30.6
3.49
31.8
3.68
33.3
3.65
34.1
3.77
35.0
3.90
6
22.1
2.59
26.4
3.17
30.6
3.61
31.8
3.71
32.9
3.76
33.7
3.77
34.6
3.92
8
22.1
2.65
26.4
3.24
30.6
3.79
31.8
3.89
32.5
3.88
33.3
3.90
34.1
3.96
10
22.1
2.71
26.4
3.31
30.6
3.94
31.8
4.02
32.1
4.04
32.9
4.06
33.7
4.08
12
22.1
2.76
26.4
3.37
30.6
4.01
31.3
4.03
31.8
4.06
32.5
4.07
33.3
4.10
14
22.1
2.81
26.4
3.44
30.5
4.05
31.0
4.06
31.3
4.08
32.1
4.09
32.9
4.19
16
22.1
2.86
26.4
3.51
30.1
4.06
30.5
4.08
30.9
4.10
31.7
4.12
32.5
4.26
18
22.1
2.91
26.4
3.58
29.7
4.20
30.1
4.22
30.5
4.24
31.3
4.28
32.1
4.32
20
22.1
2.98
26.4
3.81
29.2
4.40
29.7
4.43
30.1
4.45
30.9
4.49
31.7
4.54
21
22.1
3.06
26.4
3.94
29.1
4.51
29.5
4.53
29.9
4.55
30.7
4.60
31.5
4.64
23
22.1
3.28
26.4
4.23
28.7
4.71
29.1
4.73
29.4
4.76
30.2
4.81
31.0
4.85
25
22.1
3.50
26.4
4.53
28.3
4.92
28.6
4.94
29.1
4.97
29.9
5.02
30.7
5.07
27
22.1
3.74
26.4
4.85
27.9
5.12
28.3
5.15
28.6
5.18
29.4
5.23
30.2
5.29
29
22.1
3.99
26.4
5.18
27.4
5.33
27.8
5.36
28.3
5.39
29.1
5.45
29.9
5.50
31
22.1
4.26
26.3
5.48
27.0
5.54
27.4
5.57
27.8
5.60
28.6
5.66
29.4
5.73
33
22.1
4.54
25.8
5.69
26.6
5.75
27.0
5.78
27.4
5.81
28.3
5.88
29.0
5.94
35
22.1
4.84
25.4
5.89
26.2
5.96
26.6
5.99
27.0
6.03
27.8
6.10
28.6
6.16
37
22.1
5.15
25.0
6.11
25.8
6.18
26.2
6.21
26.6
6.25
27.4
6.32
28.2
6.39
39
22.1
5.48
24.6
6.17
25.4
6.38
25.8
6.42
26.2
6.46
27.0
6.53
27.8
6.61
41
22.1
5.77
24.3
6.23
25.1
6.44
25.6
6.48
25.9
6.52
26.7
6.55
26.7
6.67
43
22.1
5.91
24.1
6.26
25.0
6.46
25.4
6.51
25.7
6.53
26.2
6.56
26.4
6.69
45
22.1
6.21
24.0
6.32
24.7
6.52
25.2
6.55
25.3
6.56
25.5
6.58
25.9
6.81
48
22.1
6.43
23.9
6.52
24.3
6.58
24.8
6.61
25.0
6.63
24.9
6.69
25.3
6.83
120%
-5
20.4
2.32
24.3
2.81
28.3
3.32
30.2
3.62
31.7
3.78
32.4
3.90
33.1
4.00
-2
20.4
2.34
24.3
2.84
28.3
3.36
30.2
3.64
31.7
3.82
32.4
3.93
33.1
4.01
0
20.4
2.36
24.3
2.86
28.3
3.39
30.2
3.65
31.7
3.86
32.4
3.95
33.1
4.02
2
20.4
2.37
24.3
2.89
28.3
3.42
30.2
3.69
31.7
3.87
32.4
3.98
33.1
4.03
4
20.4
2.39
24.3
2.92
28.3
3.47
30.2
3.72
31.7
3.92
32.4
3.99
33.1
4.04
6
20.4
2.42
24.3
2.95
28.3
3.51
30.2
3.76
31.7
3.96
32.4
4.02
33.1
4.05
8
20.4
2.44
24.3
2.98
28.3
3.55
30.2
3.81
31.7
4.00
32.4
4.04
33.1
4.07
10
20.4
2.47
24.3
3.02
28.3
3.59
30.2
3.88
31.7
4.01
32.4
4.05
33.1
4.09
12
20.4
2.52
24.3
3.07
28.3
3.66
30.2
3.95
31.2
4.02
31.9
4.03
32.7
4.12
14
20.4
2.57
24.3
3.14
28.3
3.73
30.2
4.03
30.8
4.05
31.6
4.09
32.3
4.17
16
20.4
2.61
24.3
3.20
28.3
3.80
30.1
4.10
30.4
4.11
31.1
4.16
31.9
4.23
18
20.4
2.66
24.3
3.26
28.3
3.93
29.6
4.20
30.0
4.21
30.7
4.25
31.5
4.29
20
20.4
2.72
24.3
3.39
28.3
4.23
29.2
4.40
29.6
4.42
30.3
4.46
31.1
4.50
21
20.4
2.74
24.3
3.51
28.3
4.38
29.0
4.51
29.3
4.52
30.2
4.56
30.9
4.61
23
20.4
2.93
24.3
3.76
28.3
4.69
28.6
4.70
29.0
4.73
29.7
4.77
30.4
4.81
25
20.4
3.13
24.3
4.02
27.8
4.89
28.2
4.91
28.5
4.93
29.3
4.98
30.1
5.03
27
20.4
3.34
24.3
4.30
27.4
5.09
27.8
5.12
28.2
5.15
28.9
5.19
29.6
5.24
29
20.4
3.56
24.3
4.59
27.0
5.30
27.4
5.33
27.7
5.35
28.4
5.41
29.2
5.46
31
20.4
3.80
24.3
4.90
26.5
5.51
27.0
5.53
27.4
5.57
28.1
5.62
28.8
5.68
33
20.4
4.05
24.3
5.23
26.2
5.72
26.5
5.75
26.9
5.77
27.6
5.84
28.3
5.89
35
20.4
4.31
24.3
5.57
25.7
5.92
26.1
5.95
26.5
5.99
27.3
6.05
28.0
6.11
37
20.4
4.58
24.3
5.94
25.4
6.14
25.7
6.17
26.1
6.20
26.8
6.26
27.5
6.33
39
20.4
4.88
24.2
6.27
24.9
6.34
25.3
6.38
25.7
6.41
26.5
6.48
27.2
6.55
41
20.4
5.01
24.0
6.32
24.7
6.39
25.1
6.43
25.5
6.46
26.3
6.50
26.4
6.60
43
20.4
5.09
23.9
6.36
24.5
6.43
24.9
6.45
25.3
6.48
25.8
6.52
26.0
6.73
45
20.4
5.15
23.8
6.42
24.3
6.49
24.6
6.51
25.0
6.53
25.3
6.54
25.7
6.88
48
20.4
5.19
23.6
6.49
24.0
6.54
24.2
6.56
24.8
6.58
24.9
6.56
25.4
6.96
110%
-5
18.7
2.03
22.3
2.52
25.9
3.01
27.7
3.23
29.5
3.48
31.8
3.61
32.5
3.72
-2
18.7
2.06
22.3
2.55
25.9
3.03
27.7
3.26
29.5
3.50
31.8
3.64
32.5
3.74
0
18.7
2.09
22.3
2.57
25.9
3.06
27.7
3.28
29.5
3.54
31.8
3.68
32.5
3.79
2
18.7
2.13
22.3
2.59
25.9
3.11
27.7
3.32
29.5
3.58
31.8
3.73
32.5
3.83
4
18.7
2.17
22.3
2.62
25.9
3.13
27.7
3.36
29.5
3.63
31.8
3.79
32.5
3.87
6
18.7
2.19
22.3
2.65
25.9
3.17
27.7
3.41
29.5
3.67
31.8
3.83
32.5
3.93
8
18.7
2.21
22.3
2.69
25.9
3.20
27.7
3.45
29.5
3.72
31.8
3.85
32.5
3.97
10
18.7
2.24
22.3
2.73
25.9
3.25
27.7
3.51
29.5
3.78
31.8
3.88
32.5
4.00
12
18.7
2.29
22.3
2.79
25.9
3.31
27.7
3.58
29.5
3.85
31.4
3.94
32.0
4.06
14
18.7
2.33
22.3
2.84
25.9
3.37
27.7
3.64
29.5
3.92
31.0
3.97
31.7
4.08
16
18.7
2.37
22.3
2.89
25.9
3.44
27.7
3.71
29.5
4.00
30.6
4.01
31.2
4.13
18
18.7
2.42
22.3
2.95
25.9
3.51
27.7
3.82
29.5
4.19
30.2
4.22
30.9
4.26
20
18.7
2.46
22.3
3.01
25.9
3.71
27.7
4.10
29.1
4.39
29.8
4.43
30.4
4.47
21
18.7
2.49
22.3
3.10
25.9
3.85
27.7
4.25
28.9
4.50
29.5
4.53
30.2
4.57
23
18.7
2.60
22.3
3.32
25.9
4.13
27.7
4.56
28.4
4.70
29.2
4.74
29.8
4.78
25
18.7
2.78
22.3
3.55
25.9
4.41
27.7
4.89
28.1
4.90
28.7
4.95
29.4
4.99
27
18.7
2.96
22.3
3.79
25.9
4.72
27.3
5.09
27.6
5.11
28.4
5.15
29.0
5.20
29
18.7
3.16
22.3
4.05
25.9
5.04
26.9
5.30
27.3
5.32
27.9
5.37
28.6
5.42
31
18.7
3.37
22.3
4.32
25.9
5.38
26.5
5.50
26.8
5.53
27.5
5.57
28.2
5.63
33
18.7
3.58
22.3
4.60
25.7
5.68
26.1
5.71
26.5
5.73
27.1
5.79
27.8
5.84
35
18.7
3.81
22.3
4.90
25.3
5.88
25.7
5.91
26.0
5.95
26.6
6.00
27.4
6.06
37
18.7
4.05
22.3
5.22
24.9
6.10
25.3
6.12
25.6
6.15
26.3
6.22
26.9
6.27
39
18.7
4.31
22.3
5.56
24.5
6.30
24.8
6.33
25.2
6.37
25.8
6.43
26.6
6.49
41
18.7
4.35
22.3
5.60
24.3
6.35
24.6
6.38
25.0
6.41
25.5
6.47
25.8
6.54
43
18.7
4.40
22.3
5.68
24.1
6.39
24.5
6.42
24.8
6.45
25.3
6.50
25.4
6.67
45
18.7
4.54
22.3
5.71
23.9
6.45
24.2
6.50
24.6
6.51
25.0
6.68
25.1
6.82
48
18.7
4.70
22.3
6.19
23.5
6.49
23.8
6.55
24.3
6.58
24.6
6.70
24.8
6.90
